The height of the PD 5 Shoring System can be adjusted continuously for shoring towers and slab tables on account of the sophisticated supporting frame construction. Its carefully considered details, small number of individual components, and low weight ensure safe assembly on the jobsite. Beams can also be realised in no time with just a few additional components. The components are adapted to suit the system grid of the PERI UP modular construction kit, allowing you to integrate decking or ledgers from PERI UP Flex.
What’s more, it is even possible to achieve a load-bearing capacity of up to 47.2 kN per leg even at a height of 9.65 m and a total spindle extension of 0.65 m. This means fewer shoring towers are required, allowing you to save material on your jobsite.
Assembly and dismantling work can take place either vertically or horizontally, and you can even transport the system safely by crane or on a trolley with winch unit.
Maximum flexibility and a whole host of application possibilities
thanks to quick and continuous height and width adjustment
thanks to clever details and only a small number of individual parts
Simple and safe handling
on account of the low component weight and sophisticated frame design
Cost-effective and simple
The PD 5 Shoring System is suitable for slab formwork and beams in the average load-bearing capacity range and is ideal for
Various additional applications, such as those in the transport and industrial construction industries, can also be accommodated to a limited extent.
